Spiral® LP (Low Profile)

High Security and Speed with a Low Profile – Designed for Limited Space Applications

Spiral^® LP High-Performance Door

Combining a low profile side column design with a low headroom configuration the Spiral^® LP (Low Profile) door offers high performance and speed for high-traffic situations with limited space. This reduced profile can benefit many parking garages and other commercial structures. The Spiral LP low-profile high-performance door has sleek, crisp lines. It also features rigid, aluminum slats for strength, eliminating the need for a second security door.

With a reduced profile allowing it to fit in tighter spaces, it is the ideal low-profile parking door. It is also equally optimal for security, government, parking, and automotive dealership installations. Models designed with 9-inch tall full-vision (Spiral^® LP-FV) or full-ventilation (Spiral^® LP-VT) slats for specific applications or environments are also available.

Spiral LP is backed by a 5-year limited warranty on motor/mechanical components and materials, plus a 2-year limited warranty on electrical components.

The Rytec Spiral^® door portfolio includes models certified to withstand winds up to 175 miles per hour.

Categories: High Performance, Rytec

Request A Quote

Benefits

Low profile side columns require only 6.5 inches of side room clearance.
Special track design allows a door to fit with as little as 11 inches of headroom clearance.
Quiet, low maintenance spring-less operation.
Double walled aluminum slats, integral rubber weatherseals and heavy-duty hinge system provide solid security.

Safety

SmartSurround^® Advanced Detection & Alert System combines optical light curtains to monitor traffic and visual safety lights – all in one.
Advanced³ Light Curtain Safety System continuously monitors door opening.

SmartSurround^® Advanced Detection and Alert System

Advanced software features next-generation pattern recognition and traffic-sensing technology
4-corner perimeter guard produced by artificial intelligence, optical light curtains and high-intensity LED signaling lights
Ideal for high-traffic areas where both vehicles and pedestrians are present

Construction

Double-walled, 6-inch, clear anodized aluminum slats
Integral weatherseal between the aluminum slats
Heavy-duty hinge system for door panel assembly
Durable powder coated steel side columns and head console (excludes US/R models)

Options
