Clima Elite 5800

Polyurethane Insulated Steel Hybrid Carriage Style Garage Doors

Mix & match panel & window designs to create a one-of-a-kind carriage style garage door

A luxurious carriage style door in a one-of-a-kind design will be the envy of your neighborhood. Easy to clean woodgrain textured panels are 2” thick and all models have our standard white finish, which may be field painted to match any home façade. With 144 mix and match panel and window designs available and our precision cut Extira® composite wood overlays, it’s possible to create a custom carriage style garage door that perfectly complements your home.

In addition to a beautiful door, you can count on a weather tight seal with our proven insulated (sandwich) panel construction that consists of tongue and groove section joints, proprietary polyurethane core, and steel skin (R-15.7 thermal rating).

Categories: Garage Doors, Hormann, Steel Doors

Request A Quote

Characteristic
Insulation value	U-Factor 0.21 / R-15.7
Material	Steel with composite wood overlays
Thickness	2″ door, 1.5″ Insulation
Design options	144 Panel + window designs
Colors	White + field paint option
Warranty	Door: Ltd Lifetime – Hardware: 5yr – Springs: 3yr

Panel Construction

The industry leader in innovative door safety, insulation, and strength

Precise Thermal Break

Increased thermal efficiency is achieved by our conduction-resistant thermal break.

Reinforced Mounting Steel

Triple-reinforced steel fold extends across the entire section for robust hardware mounting. An internal steel layer creates additional stability.

Insulated Tongue & Groove

Our joints are sealed with insulating foam and joint tape to reduce air flow heat loss.

Proprietary Urethane Blend

Perfected over generations, our precisely engineered polyurethane outperforms its competitors in strength, energy efficiency, and density every time.

Proprietary Safety Brackets

Our reinforced safety bottom brackets and red safety screws create a double layer of built-in safety for the user.

Steel Construction

Our top-of-the-line galvanized steel is treated with several layers of strength and weather resistance.

Section Detail

Our Clima Elite window mullion is joint-free and has attractive detailing with crisp corners. The glass is sealed with bonding tape around the perimeter of the window and on the back of the grid, providing superior weather protection and greater ease when field painting.
